15 inch Multiple CPU Options Touch POS Terminal with White Color（Model No.:T320+)

15 inch Multiple CPU Options Touch POS Terminal with White Color（Model No.:T320+)

15 inch All in one Windows Touch Screen POS Machine POS system J6412/i3/i5 CPU for optional; 4gb/8gb/16gb optional; 128gb/256gb/512gb optiona; VFD/9.7"/11.6" Customer Display optional; MSR/NFC optional; Rich I/O interface; 12Months Warranty; Clean Cable Management

item no.:
T320+
lead time:
7-15days
product orgin:
Shenzhen,China
shipping port:
Shenzhen port
payment:
50% Deposit in advance and Balance before shi
color:
Silver+White/ Silver+Yellow
Motherboard:
I3 / I5 / E3950
Main screen size:
15 inch
Monitor resolution:
1024*768
Second screen:
VFD 220 / VGA, 9.7
Quality warranty:
2 years

inquiry now

feature
specification

15 inch All in one Windows Touch Screen POS Machine POS system

J6412/i3/i5 CPU for optional;

4gb/8gb/16gb optional;

128gb/256gb/512gb optiona;

VFD/9.7"/11.6" Customer Display optional;

MSR/NFC optional

Model Number		T320+
CPU Support		Intel Elkhart Lake J6412 2.0GHz (up to 2.6GHz,1.5MB cache), FANLESS	Intel Core I3 Skylake, FAN	Intel Core I5 Skylake, FAN
System Memory		1 x DDR4,SO-DIMM, 4GB (Max. 32GB)	1 xDDR4, SO-DIMM, 4GB (Max. 16GB)
Storage	SATA	N/A
	mSATA/M.2	1 xmSATA / M.2 SSD 128GB (64G/256G/512G optional )	1 x M.2 SSD 128GB (64G/256G/512G optional )
LCD	Size	15" TFT LCD Panel
	Brightness	250 ~ 450 cd/m2 (Typ.)
	Resolution	1024 x 768
Touch Screen		True-Flat Projected Capacitive Touch
Tilt Angle		0 ~ 60 degree
External I/O Port	USB	2 x USB 3.0+3xUSB2.0
	Serial port	2 x Serial port (DB9);
	VGA	1 x VGA
	HDMI	1 x HDMI
	Cash Drawer Port	N/A
	LAN	1 x LAN (10/100/1000Mb)
	Audio	1 x Audio
	DC-In	1 x DC In
	DC-Out	1 x DC-Out(12V power)
	Power Switch	1 x Power Switch
Speaker		2 x 2W Speaker (Optional)
Power		External power adapter, 12V-5A/60W
EMC Safety		CE, ROHS, UKCA, FCC
Environment	Operating Temperature	0°C ~ 35°C
	Storage Temperature	-15°C ~ 60°C
	Operating Humidity	20% - 85% RH non condensing
	Storage Humidity	20% - 85% RH non condensing
OS Support		Windows11/10 LTSC/Ubuntu 20.0.4	Windows7/10 LTSC/Ubuntu 18.0.4
Dimension (W x D x H)		370220365mm
Weight (N.W./G.W.)		4.57Kg/6.35Kg
Wall Mount		VESA 75 x 75mm
optional	CPU	E3950, i3 Haswell, i5 Boardwell, i3/i5 Kaby Lake, i5 CoffeeLake, i3/i5 Tigerlake
	WiFi	m.2PCI-E WiFi/BT
	MSR (USB)	MSR + iButton (Combo) o r MSR +RFID (Combo) ,USB(VCOM optional) , 1、2 、3 Track, ISO7810, 7811-1/2/3/4/5, IBM,AAMVA,JIS-2 Standard
	Scanner	N/A
	Customer display	VFD display, USB (VCOM), 2x20 characters
	2nd Display	VGA, 9.7" (1024768) VGA,11.6" (1366768) VGA,12.1" (1280*800)
